水切网式固液分离系统产品简介
水切网式固液分离机是利用楔形钢棒制成的不锈钢平面过滤筛面，通过溢流堰均匀分布待处理废水，使其在筛网表面的间隙小、平滑下进行过滤。背面间隙大，排水顺畅，不易阻塞；固态物质被截留，过滤后的水从筛板缝隙中流出，同时在水力作用下，固态物质被推到筛板下端的螺旋槽里，由螺旋向前推进到挤压段进行再次脱水。
该系统能有效地降低水中悬浮物浓度，减轻后续工序的处理负荷。同时也用于工业生产中进行固液分离和回收有用物质，是一种优良的过滤或回收悬浮物、漂浮物、沉淀物等固态或胶体物质的设备。
产品特色：
网管式挤压适应腐质污水，如高床式猪场、高浓度污water设计，其运转过程能稳定的保持固体含水率65%，非一般螺旋挤压可比。
前期过滤利用自带重力工作，无需额外能耗；挤压部分功率低，能耗小。
突破欧、美、日技术，以中国自行生产为主，其间隙0.4-0.5mm，大单台处理量大，可后段处理最轻松使用年限最长。
齿轮式逆向清洗机构，无需耗材如钢索电气零件，可再生使用。
自动探测满足条件启动、运行至停机时自动洗网功能，便于维护清洁。
适用范围：
用于养殖业、小型工业废water处理去除悬浮物、漂浮material等solid material；
用于造纸业酒精业淀粉业食品加工等行业回收纺维渣料等有用material；
用于污泥或河道清淤预processing。
结构外形及工作原理图示：（上海盾旗依据牧原股份粪污processing现状开发了大处理量water切net machine，将一台machine适配1万头猪场提高到了2万头）
全自动water切net solidliquid separation system product price:
DGF-1Z（70）：Processing capacity: (10-20m³/h)
Pollution water lift system: 2,200W cutting submersible pump 1 unit, head 10 meters, pipe diameter 3 inches.
Separation and pressing system: Main body of the equipment with a thickness of 2 mm made of stainless steel, press power of 2,200W; The press part is treated with hard chrome plating on stainless steel to increase the service life by 2 times; Filter net made of precision woven mesh (size:800X1220mm), filter accuracy:0 μm; Washing net self-suction water pump with a power rating of up to250W washing net machine.
DGF-2Z（120）：Processing capacity: (30-40m³/h)
...
DGF-3Z（150）：Processing capacity:(45-60m³/h)
Control System:
304 Stainless Steel Automatic Control Cabinet
Automatic and manual control modes available
Can be controlled based on high/low water level to start/stop pumps
Can control startup/shutdown for stirring motor, pressing motor, washing motor and vibration motor.
Equipment Accessories:
(Excluding quality stirring systems)
Device Name Unit Quantity Main Parameters Remark
Machine Body Set
Board Thickness ≥12mm Anti-corrosion Door Wall ≥8mm
Slanting Filter Net Set
Filter Mesh Hole Size ≤500μm Net Thickness ≥6mm
Transportation Pressing System Set
Transport Leaflet Width ≥50mm Pressing Leaflet Width ≤80mm Pressing Mesh Hole Size ≤500μm Transport Axial Diameter ≥60/65mm
Automatic or Manual Control Switch Basic Control System Set
Casing Material SUS304 Non-stick Steel Wall Thickness ≥16mn Protection Level IP55 Electrical Components Tai'an Brand Bearings CU Main Cable Length Meter Shanghai Pudong Area Total Surface Area m² Power Consumption Per Hour KW
Full Automation Additional Systems
Liquid Level Probe Material SUS304 Material
Screen Cleaning System Full Screen Self-cleaning System High Frequency Vibration Screen Pratistha Model PR40A03
